Arturia - AudioFuse Studio Rev2 Audio Interface, Black #AUDIOFUSESTUDIOREV2

Premium desktop audio interface

AudioFuse Studio returns in an elevated Rev2 edition, featuring optimized preamps and an updated Bluetooth module. Combining pristine conversion with extensive connectivity, it’s the perfect all-in-one hub for any professional recording studio.

Pristine Quality

AudioFuse Studio Rev2 features 4 DiscretePRO® preamps to track your music, and a pristine analog signal path to reveal every nuance of your audio.

Each unit comes with its individual measurement certificate, providing a super-low Equivalent Input Noise (EIN) to capture every subtle detail, and a huge 72dB gain to drive even the quietest ribbon mics.

Every detail is captured with absolute transparency and faithful accuracy, preserving the true character of your source. Latest-generation 24-bit AD/DA converters running at up to 192kHz carry that signal into your DAW and back out again.

Ultimate Creative Hub

A u dioFuse Studio Rev2 features 8 analog inputs—comprising 4 mic/line/instrument inputs, 4 line inputs including a dedicated Phono input for vinyl—alongside 4 line outputs, 4 analog inserts, and 2 Aux/guitar reamping outputs.

Combined with robust digital connectivity (ADAT, SPDIF, Word Clock, MIDI, USB-C), an upgraded Bluetooth® receiver, and advanced monitoring capabilities—including the ability to drive 2 speaker sets and dual independent headphone outputs— it serves as the ultimate all-in-one hub for any studio configuration.

Complete Production Bundle

AudioFuse Studio Rev2 comes bundled with the AudioFuse Creative Suite, a premium, expanding collection of software effects and instruments featuring titles from the acclaimed FX Collection.

Preamps, compressors, reverbs, delays and modulation, plus virtual instruments: everything needed to mix, master and finish a record from the moment the box is opened.

Included Software

• Analog Lab Intro
• Pre 1973
• Pre V76
• Pre TridA
• Comp FET-76
• Comp DIODE-609
• Delay TAPE-201
• Filter MINI
• Rev PLATE-140 Chorus JUN-6 Phaser BI-TRON.

Features & Specifications

• 18 inputs, 20 outputs channels (8 total analog inputs)
• 24-bit latest generation AD/DA converters at up to 192kHz sampling rate.
• 4 mic/instrument/line preamps with DiscretePRO® technology (-129dBu EIN, 119dB dynamic range, dedicated hands-on controls)
• 4 additional line inputs, with inputs 5-6 commutable to phono RIAA preamp.
• 4 analog inserts on channel 1-4
• Bluetooth audio receiver supporting aptX©, aptX™ HD, aptX™ Low Latency, and AAC©
• 2 pairs of speaker analog outputs on balanced TRS Jack
• 2 independent stereo headphones outputs, both 6.35 and 3.5mm TRS, with independent sources, controls, and metering
• 2 independent analog line outputs with reamp capability (instrument level output)
• USB-C interface compatible with PC & Mac, fully USB 2.0 compatible, with multi-port USB hub
• MIDI and connectivity
• Complete monitoring section with individual level control for speakers and phones
• Direct monitoring ultra-low latency internal mixers
• 8 digital ADAT inputs/outputs up to 96kHz
• S/PDIF i/o or Word clock input, output/thru on Cinch RCA
• DiscretePRO® Individual audio performance certificate delivered with each unit.
• Robust metal desktop chassis

Ecosystem Update

We support our products on the long run: the AudioFuse ecosystem keeps evolving with free updates. Your unit is cared for, years after purchase.

Audio Fuse Control Center 2.5.0 brings a new preset import/export feature to all existing AudioFuse devices, allowing users to save and recall custom presets from their computer.

Audio Fuse Control Center 2.5.0 brings a new preset import/export feature to all existing AudioFuse devices, allowing users to save and recall custom presets from their computer.
